Signamax MI10040 I-1100 10/100 to 100FX PoE+ Industrial Media Converter, SC/SM

Description

Signamax MI10040 I-1100 10/100 to 100FX PoE+ Industrial Media Converter, SC/SM

• Rugged IP40 enclosure with integrated DIN-Rail mounting bracket
• Wide operating temperature: -40 to 167 °F (-40 to 75 °C)
• Surge protection (4kV LAN) for extreme outdoor environments
• Redundant terminal block DC inputs
• Overload and reverse polarity protection
• Zero touch Plug and Play connectivity
• Non-Blocking, wire speed media conversion
• Up to 60 watts PoE+ support
• Fixed fiber Singlemode
• 5 year hardware warranty & support at no additional cost

• PORTS

RJ-45 Ports: 2 – 10/100
Fiber Ports: 1 – 100FX SC/SM
PoE Ports: 2

• PoE

PoE Budget: 60W
Support IEEE 802.3af/IEEE802.3at on each port
Dynamic Power Allocation

• PERFORMANCE

Wirespeed forwarding

• LAYER 2

IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3u 100BaseFX
IEEE 802.3 Auto-Negotiate
IEEE 802.3x Flow Control

• ELECTRICAL CHARACTERISTICS

Max Power Consumption: 64W
MTBF: 539K hrs
DC Input Range: 48 ~ 57V DC, Dual Redundant
4kV LAN surge protection
Reverse polarity and overload current protection

• PHYSICAL CHARACTERISTICS

Dimensions: 1.2” W x 4.7” H x 3.9” D (3 x 11.9 x 10 cm)
Weight: 0.78 lb (0.35 kg)
Housing: IP40 protection, aluminum alloy case
Mounting: DIN-Rail mounting (included)

• ENVIRONMENTAL REQUIREMENTS

Operating Temperature: -40°F to 167°F (-40°C to 75°C)
Storage Temperature: -40 to 185°F (-40 to 85°C)
Operating/Storage Humidity: 5 to 95% (non-condensing)

• CERTIFICATIONS

Emissions: CE Mark: EN 55022, Class A; FCC Part 15 Class A
Safety: CE/LVD EN60950

• WARRANTY

Five years
